Pineapple Processing Line by Gofun Tailored Capacity Sterilization FDA Compliant

• Combined peeling, coring, and slicing unit with a processing efficiency of ≥5 tons per hour.
• Utilization of an optical sorting system with defect recognition accuracy of ≥99.2%.
• Implementation of a low-temperature pasteurization process (72°C/15s) for 5-log sterilization efficiency.

• Adoption of a vacuum instant concentration system with a vitamin C retention rate exceeding 85%.
• Application of non-thermal drying technology maintaining water activity below 0.65.

• Canned Pineapple:
  Solid content of ≥65%, suitable for baking ingredients and ready-to-eat desserts.
• NFC Pineapple Juice:
  Turbidity stability exceeding 6 months, ideal for premium beverages, cocktails, and wine bases.
• Freeze-Dried Pineapple Granules:
  Rehydration ratio of 1:4.5, perfect for breakfast cereals and snacks.
• Pineapple Jam:
  Soluble solids of ≥68°Brix, suitable for baking fillings and dairy applications.
• Fermented Pineapple Wine:
  Alcohol content of 12±1%vol, targeting the specialty fruit wine market.
• Probiotic Pineapple Yogurt:
  Viable bacteria count of ≥1×10^8 CFU/g, designed for functional dairy products.

• Utilization of an aseptic cold filling system suitable for PET and Tetra Pak packaging.
• Usage of nitrogen-filled preservation packaging with residual oxygen content ≤0.5%.
• Integration of degradable stand-up bag packaging using PLA composite material.

This HACCP-certified solution achieves a raw material utilization rate exceeding 92% and a wastewater reuse rate of 40%, facilitating the development of a comprehensive pineapple product industry chain.

Shanghai Gofun Machinery Company has garnered recognition for its highly efficient pineapple processing line, distinguished by innovative attributes like water-saving design, superior extraction rates, stringent quality control, and advanced safety protocols for operators.

The pineapple processing production line encompasses pivotal stages, beginning with a meticulous cleaning process to eliminate impurities from the pineapples. The sorted pineapples are then crushed to extract juice efficiently, employing a belt juice extraction method to optimize extraction rates.

To enhance the flavor and aroma of the pineapple products, enzymatic hydrolysis is employed. The extracted juice undergoes filtration to remove any remaining solids or impurities. Through evaporation, the juice is concentrated, resulting in a more pronounced flavor profile.

Stringent measures are enacted to ensure product safety and microbial control, including rigorous sterilization procedures. Ultimately, the processed pineapple products are carefully filled into suitable packaging options.

In essence, Shanghai Gofun Machinery Company's pineapple processing line is highly esteemed for its remarkable efficiency, innovative water-saving design, elevated extraction rates, strict quality control, and comprehensive safety measures for operators, positioning it as a top-tier choice for producing premium-grade pineapple products.

1. High processing capacity: varied from 20 T/day to 1500 T/day.
2. Multiple use: the processing line can deal with similar characteristics of fruits.
3. Automatic disinfection liquid concentration control system: effectively guarantee the sterilization effect and control the disinfection residue.
4. High output: Tubular type pasteurizer is used to improve the high output percentage of pineapple.
5. High efficiency: The high-efficient belt juice extractor is adopted, which improves the juice extraction efficiency and yield.
6. Energy-saving: Automatic PLC controlled production process to reduce the labor intensity and improve production efficiency.
7. Low-temperature vacuum evaporation: reduce the flavor substances and nutrient losses.
8. Energy recovering: Various energy recovery measures are adopted, which improves the energy utilization efficiency and greatly reduces the production cost.
9. Healthy and safety: UHT sterilizer and aseptic filling machine, isolated from the pollution of bacteria, ensure the safety of the food and extend the shelf life of the product.
10. Label-saving: The complete production line is equipped with a self-contained CIP (clean-in-place) system, which reduces labor intensity and guarantees a high level of hygiene.

FRESH PINEAPPLE ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ CRUSHING ⇒ BELT TYPE JUICE EXTRACTING ⇒ ENZYMATIC HYDROLYSIS & FILTRATION SYSTEM ⇒ EVAPORATING ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒ STORAGE OR BLENDING

FRESH PINEAPPLE ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ CRUSHING ⇒ BELT TYPE JUICE EXTRACTING ⇒ ENZYMATIC HYDROLYSIS & FILTRATION SYSTEM ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒ STORAGE OR BLENDING

PINEAPPLE CONCENTRATION⇒ BLENDING SYSTEM ⇒ STERILIZING ⇒ FILLING ⇒ PASTEURIZING TUNNEL ⇒ PACKAGING

FRESH PINEAPPLE ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ CUTTING ⇒ BLANCHING ⇒ DRYING ⇒ PACKING

Shanghai Gofun Machinery Company has earned industry recognition for its high-efficiency pineapple processing line, which stands out with innovative features: a water-saving design (reducing water consumption by 20-30% compared to conventional lines), superior juice extraction rates, strict quality control systems, and advanced safety protocols to protect operators.​
Beyond the core processing line, the company’s strength further lies in its customized solutions—a team of professional engineers specializes in designing and producing tailored equipment lists. These solutions are fully aligned with customers’ specific requirements, including production capacity needs (from small-batch to large-scale), local voltage specifications (adapting to global electrical standards), and workshop space conditions. When designing the production process, crucial on-site factors are also taken into account, such as water supply pressure, power supply stability, steam availability, and other supporting resources—ensuring seamless integration of the processing line into the customer’s existing workflow.​
Stringent quality control runs through every link: All materials used in the equipment are constructed from SUS304 stainless steel. This food-grade material not only meets global hygiene standards (complying with FDA, CE, and other certifications) but also offers excellent corrosion resistance and durability, suitable for the acidic environment of pineapple processing and reducing long-term maintenance costs.​
To further guarantee customer satisfaction and equipment reliability, pre-shipment testing services are provided: Customers are invited to visit Shanghai Gofun Machinery’s facility in person to inspect the equipment and conduct on-site test runs. This hands-on verification allows customers to confirm that the processing line meets their expected performance, operating standards, and product quality requirements—eliminating concerns about equipment compatibility or functionality before delivery.​
The pineapple processing production line itself covers a complete, streamlined workflow across key stages:​
Meticulous Cleaning: Fresh pineapples first undergo a thorough cleaning process to remove surface impurities, pesticides, and residual dirt—laying the foundation for product safety.​
Efficient Crushing & Juice Extraction: Sorted pineapples are crushed, then processed via a belt juice extraction method. This specialized technology maximizes extraction rates, ensuring full utilization of pineapple pulp and minimizing raw material waste.​
Flavor Enhancement & Filtration: Enzymatic hydrolysis is applied to enhance the natural sweetness and aromatic profile of pineapple products. The extracted juice is then filtered to eliminate remaining solids or fine impurities, ensuring a smooth texture.​
Concentration & Sterilization: The filtered juice is concentrated through evaporation, intensifying its flavor while reducing volume for easier storage and transport. Rigorous sterilization procedures are also implemented to achieve microbial control, meeting global food safety standards.​
Final Filling: The processed pineapple products (including juice, concentrates, or pulp) are carefully filled into suitable packaging—adapting to diverse market needs such as bottles, cans, or aseptic bags.​
In summary, Shanghai Gofun Machinery Company’s pineapple processing line, combined with its customized solutions, SUS304 material quality, and pre-shipment testing services, becomes a comprehensive and reliable choice. Its exceptional efficiency, innovative water-saving design, elevated extraction rates, and customer-centric services make it a top-tier partner for enterprises aiming to produce premium-grade pineapple products, whether for retail beverages, food ingredients, or industrial applications.

All machines are manufactured according to the contract and drawings. After receiving full payment, we will arrange for shipment in the shortest possible time. All exported machines are packaged in wooden crates. We will send installation instructions together with the machines.

After machines reach buyer’s workshop, we will arrange our engineers to install. The quality guarantee is one year. We will supply whole-life service.
